VEX Robotics Motor Data - 775pro (217-4347)

The 775pro motor was designed in collaboration with West Coast Products specifically for high speed applications such as intakes, conveyors and shooter wheels. It packs the power of a CIM Motor into a small and lightweight package and pairs perfectly with the VersaPlanetary Gearbox!



Published Specification

Experimental Data

Free Speed (RPM)

18700 (+/- 10%)

18730

Free Current (A)

0.7

0.7

Maximum Power (W)

347

347

Stall Torque (N · m)

0.71

0.71

Stall Current (A)

134

134
Click to expand Motor Curve Data
Speed (RPM) Torque (N·m) Current (A) Supplied Power (W) Output Power (W) Efficiency (%) Power Dissipation (W)
0 0.708 133.613 1603.356 0 0 1603.356
187.34 0.70092 132.284 1587.408 13.751 0.866 1573.657
374.681 0.69384 130.955 1571.46 27.224 1.732 1544.236
562.021 0.68676 129.626 1555.512 40.419 2.598 1515.093
749.362 0.67968 128.296 1539.552 53.337 3.464 1486.215
936.702 0.6726 126.967 1523.604 65.976 4.33 1457.628
1124.043 0.66552 125.638 1507.656 78.338 5.196 1429.318
1311.383 0.65844 124.309 1491.708 90.422 6.062 1401.286
1498.724 0.65136 122.98 1475.76 102.228 6.927 1373.532
1686.064 0.64428 121.651 1459.812 113.757 7.793 1346.055
1873.405 0.6372 120.322 1443.864 125.007 8.658 1318.857
2060.745 0.63012 118.992 1427.904 135.98 9.523 1291.924
2248.086 0.62304 117.663 1411.956 146.675 10.388 1265.281
2435.426 0.61596 116.334 1396.008 157.093 11.253 1238.915
2622.767 0.60888 115.005 1380.06 167.232 12.118 1212.828
2810.107 0.6018 113.676 1364.112 177.094 12.982 1187.018
2997.448 0.59472 112.347 1348.164 186.678 13.847 1161.486
3184.788 0.58764 111.018 1332.216 195.984 14.711 1136.232
3372.129 0.58056 109.688 1316.256 205.012 15.575 1111.244
3559.469 0.57348 108.359 1300.308 213.763 16.439 1086.545
3746.81 0.5664 107.03 1284.36 222.236 17.303 1062.124
3934.15 0.55932 105.701 1268.412 230.43 18.167 1037.982
4121.491 0.55224 104.372 1252.464 238.348 19.03 1014.116
4308.831 0.54516 103.043 1236.516 245.987 19.894 990.529
4496.172 0.53808 101.714 1220.568 253.349 20.757 967.219
4683.512 0.531 100.385 1204.62 260.432 21.619 944.188
4870.853 0.52392 99.055 1188.66 267.238 22.482 921.422
5058.193 0.51684 97.726 1172.712 273.766 23.345 898.946
5245.534 0.50976 96.397 1156.764 280.017 24.207 876.747
5432.874 0.50268 95.068 1140.816 285.989 25.069 854.827
5620.215 0.4956 93.739 1124.868 291.684 25.931 833.184
5807.555 0.48852 92.41 1108.92 297.101 26.792 811.819
5994.896 0.48144 91.081 1092.972 302.24 27.653 790.732
6182.236 0.47436 89.751 1077.012 307.102 28.514 769.91
6369.577 0.46728 88.422 1061.064 311.685 29.375 749.379
6556.917 0.4602 87.093 1045.116 315.991 30.235 729.125
6744.258 0.45312 85.764 1029.168 320.019 31.095 709.149
6931.598 0.44604 84.435 1013.22 323.769 31.954 689.451
7118.939 0.43896 83.106 997.272 327.242 32.814 670.03
7306.279 0.43188 81.777 981.324 330.436 33.672 650.888
7493.62 0.4248 80.447 965.364 333.353 34.531 632.011
7680.96 0.41772 79.118 949.416 335.992 35.389 613.424
7868.301 0.41064 77.789 933.468 338.354 36.247 595.114
8055.641 0.40356 76.46 917.52 340.437 37.104 577.083
8242.982 0.39648 75.131 901.572 342.243 37.961 559.329
8430.322 0.3894 73.802 885.624 343.771 38.817 541.853
8617.663 0.38232 72.473 869.676 345.021 39.672 524.655
8805.003 0.37524 71.143 853.716 345.993 40.528 507.723
8992.344 0.36816 69.814 837.768 346.687 41.382 491.081
9179.684 0.36108 68.485 821.82 347.104 42.236 474.716
9367.025 0.354 67.156 805.872 347.243 43.089 458.629
9554.365 0.34692 65.827 789.924 347.104 43.941 442.82
9741.705 0.33984 64.498 773.976 346.687 44.793 427.289
9929.046 0.33276 63.169 758.028 345.993 45.644 412.035
10116.386 0.32568 61.839 742.068 345.021 46.495 397.047
10303.727 0.3186 60.51 726.12 343.771 47.344 382.349
10491.067 0.31152 59.181 710.172 342.243 48.192 367.929
10678.408 0.30444 57.852 694.224 340.437 49.038 353.787
10865.748 0.29736 56.523 678.276 338.354 49.884 339.922
11053.089 0.29028 55.194 662.328 335.992 50.729 326.336
11240.429 0.2832 53.865 646.38 333.353 51.572 313.027
11427.77 0.27612 52.535 630.42 330.436 52.415 299.984
11615.11 0.26904 51.206 614.472 327.242 53.256 287.23
11802.451 0.26196 49.877 598.524 323.769 54.095 274.755
11989.791 0.25488 48.548 582.576 320.019 54.932 262.557
12177.132 0.2478 47.219 566.628 315.991 55.767 250.637
12364.472 0.24072 45.89 550.68 311.685 56.6 238.995
12551.813 0.23364 44.561 534.732 307.102 57.431 227.63
12739.153 0.22656 43.231 518.772 302.24 58.261 216.532
12926.494 0.21948 41.902 502.824 297.101 59.086 205.723
13113.834 0.2124 40.573 486.876 291.684 59.909 195.192
13301.175 0.20532 39.244 470.928 285.989 60.729 184.939
13488.515 0.19824 37.915 454.98 280.017 61.545 174.963
13675.856 0.19116 36.586 439.032 273.766 62.357 165.266
13863.196 0.18408 35.257 423.084 267.238 63.164 155.846
14050.537 0.177 33.928 407.136 260.432 63.967 146.704
14237.877 0.16992 32.598 391.176 253.349 64.766 137.827
14425.218 0.16284 31.269 375.228 245.987 65.557 129.241
14612.558 0.15576 29.94 359.28 238.348 66.34 120.932
14799.899 0.14868 28.611 343.332 230.43 67.116 112.902
14987.239 0.1416 27.282 327.384 222.236 67.882 105.148
15174.58 0.13452 25.953 311.436 213.763 68.638 97.673
15361.92 0.12744 24.624 295.488 205.012 69.381 90.476
15549.261 0.12036 23.294 279.528 195.984 70.112 83.544
15736.601 0.11328 21.965 263.58 186.678 70.824 76.902
15923.942 0.1062 20.636 247.632 177.094 71.515 70.538
16111.282 0.09912 19.307 231.684 167.232 72.181 64.452
16298.623 0.09204 17.978 215.736 157.093 72.817 58.643
16485.963 0.08496 16.649 199.788 146.675 73.415 53.113
16673.304 0.07788 15.32 183.84 135.98 73.966 47.86
16860.644 0.0708 13.99 167.88 125.007 74.462 42.873
17047.985 0.06372 12.661 151.932 113.757 74.874 38.175
17235.325 0.05664 11.332 135.984 102.228 75.176 33.756
17422.666 0.04956 10.003 120.036 90.422 75.329 29.614
17610.006 0.04248 8.674 104.088 78.338 75.261 25.75
17797.347 0.0354 7.345 88.14 65.976 74.854 22.164
17984.687 0.02832 6.016 72.192 53.337 73.882 18.855
18172.028 0.02124 4.686 56.232 40.419 71.879 15.813
18359.368 0.01416 3.357 40.284 27.224 67.58 13.06
18546.709 0.00708 2.028 24.336 13.751 56.505 10.585
18734.049 0 0.699 8.388 0 0 8.388
Click to expand Motor Curve Data
Speed (RPM) Torque (N·m) Current (A) Supplied Power (W) Output Power (W) Efficiency (%) Power Dissipation (W)
0 0.521 102.108 1225.296 0 0 1225.296
154.219 0.51579 101.087 1213.044 8.33 0.687 1204.714
308.439 0.51058 100.066 1200.792 16.492 1.373 1184.3
462.658 0.50537 99.045 1188.54 24.485 2.06 1164.055
616.878 0.50016 98.024 1176.288 32.31 2.747 1143.978
771.097 0.49495 97.003 1164.036 39.967 3.433 1124.069
925.317 0.48974 95.982 1151.784 47.455 4.12 1104.329
1079.536 0.48453 94.96 1139.52 54.776 4.807 1084.744
1233.755 0.47932 93.939 1127.268 61.927 5.494 1065.341
1387.975 0.47411 92.918 1115.016 68.911 6.18 1046.105
1542.194 0.4689 91.897 1102.764 75.726 6.867 1027.038
1696.414 0.46369 90.876 1090.512 82.374 7.554 1008.138
1850.633 0.45848 89.855 1078.26 88.852 8.24 989.408
2004.852 0.45327 88.834 1066.008 95.163 8.927 970.845
2159.072 0.44806 87.813 1053.756 101.305 9.614 952.451
2313.291 0.44285 86.792 1041.504 107.279 10.3 934.225
2467.511 0.43764 85.771 1029.252 113.085 10.987 916.167
2621.73 0.43243 84.75 1017 118.722 11.674 898.278
2775.95 0.42722 83.729 1004.748 124.191 12.36 880.557
2930.169 0.42201 82.707 992.484 129.492 13.047 862.992
3084.388 0.4168 81.686 980.232 134.625 13.734 845.607
3238.608 0.41159 80.665 967.98 139.589 14.421 828.391
3392.827 0.40638 79.644 955.728 144.385 15.107 811.343
3547.047 0.40117 78.623 943.476 149.013 15.794 794.463
3701.266 0.39596 77.602 931.224 153.472 16.481 777.752
3855.486 0.39075 76.581 918.972 157.764 17.167 761.208
4009.705 0.38554 75.56 906.72 161.886 17.854 744.834
4163.924 0.38033 74.539 894.468 165.841 18.541 728.627
4318.144 0.37512 73.518 882.216 169.627 19.227 712.589
4472.363 0.36991 72.497 869.964 173.245 19.914 696.719
4626.583 0.3647 71.476 857.712 176.695 20.601 681.017
4780.802 0.35949 70.455 845.46 179.977 21.287 665.483
4935.021 0.35428 69.433 833.196 183.09 21.974 650.106
5089.241 0.34907 68.412 820.944 186.035 22.661 634.909
5243.46 0.34386 67.391 808.692 188.811 23.348 619.881
5397.68 0.33865 66.37 796.44 191.42 24.034 605.02
5551.899 0.33344 65.349 784.188 193.86 24.721 590.328
5706.119 0.32823 64.328 771.936 196.132 25.408 575.804
5860.338 0.32302 63.307 759.684 198.235 26.094 561.449
6014.557 0.31781 62.286 747.432 200.17 26.781 547.262
6168.777 0.3126 61.265 735.18 201.937 27.468 533.243
6322.996 0.30739 60.244 722.928 203.536 28.154 519.392
6477.216 0.30218 59.223 710.676 204.966 28.841 505.71
6631.435 0.29697 58.202 698.424 206.229 29.528 492.195
6785.654 0.29176 57.18 686.16 207.322 30.215 478.838
6939.874 0.28655 56.159 673.908 208.248 30.902 465.66
7094.093 0.28134 55.138 661.656 209.005 31.588 452.651
7248.313 0.27613 54.117 649.404 209.594 32.275 439.81
7402.532 0.27092 53.096 637.152 210.015 32.962 427.137
7556.752 0.26571 52.075 624.9 210.267 33.648 414.633
7710.971 0.2605 51.054 612.648 210.351 34.335 402.297
7865.19 0.25529 50.033 600.396 210.267 35.021 390.129
8019.41 0.25008 49.012 588.144 210.015 35.708 378.129
8173.629 0.24487 47.991 575.892 209.594 36.395 366.298
8327.849 0.23966 46.97 563.64 209.005 37.081 354.635
8482.068 0.23445 45.949 551.388 208.248 37.768 343.14
8636.288 0.22924 44.928 539.136 207.322 38.454 331.814
8790.507 0.22403 43.906 526.872 206.229 39.142 320.643
8944.726 0.21882 42.885 514.62 204.966 39.829 309.654
9098.946 0.21361 41.864 502.368 203.536 40.515 298.832
9253.165 0.2084 40.843 490.116 201.937 41.202 288.179
9407.385 0.20319 39.822 477.864 200.17 41.888 277.694
9561.604 0.19798 38.801 465.612 198.235 42.575 267.377
9715.823 0.19277 37.78 453.36 196.132 43.262 257.228
9870.043 0.18756 36.759 441.108 193.86 43.948 247.248
10024.262 0.18235 35.738 428.856 191.42 44.635 237.436
10178.482 0.17714 34.717 416.604 188.811 45.321 227.793
10332.701 0.17193 33.696 404.352 186.035 46.008 218.317
10486.921 0.16672 32.675 392.1 183.09 46.695 209.01
10641.14 0.16151 31.653 379.836 179.977 47.383 199.859
10795.359 0.1563 30.632 367.584 176.695 48.069 190.889
10949.579 0.15109 29.611 355.332 173.245 48.756 182.087
11103.798 0.14588 28.59 343.08 169.627 49.442 173.453
11258.018 0.14067 27.569 330.828 165.841 50.129 164.987
11412.237 0.13546 26.548 318.576 161.886 50.816 156.69
11566.457 0.13025 25.527 306.324 157.764 51.502 148.56
11720.676 0.12504 24.506 294.072 153.472 52.189 140.6
11874.895 0.11983 23.485 281.82 149.013 52.875 132.807
12029.115 0.11462 22.464 269.568 144.385 53.562 125.183
12183.334 0.10941 21.443 257.316 139.589 54.248 117.727
12337.554 0.1042 20.422 245.064 134.625 54.935 110.439
12491.773 0.09899 19.401 232.812 129.492 55.621 103.32
12645.992 0.09378 18.379 220.548 124.191 56.31 96.357
12800.212 0.08857 17.358 208.296 118.722 56.997 89.574
12954.431 0.08336 16.337 196.044 113.085 57.683 82.959
13108.651 0.07815 15.316 183.792 107.279 58.37 76.513
13262.87 0.07294 14.295 171.54 101.305 59.056 70.235
13417.09 0.06773 13.274 159.288 95.163 59.743 64.125
13571.309 0.06252 12.253 147.036 88.852 60.429 58.184
13725.528 0.05731 11.232 134.784 82.374 61.116 52.41
13879.748 0.0521 10.211 122.532 75.727 61.802 46.805
14033.967 0.04689 9.19 110.28 68.911 62.487 41.369
14188.187 0.04168 8.169 98.028 61.927 63.173 36.101
14342.406 0.03647 7.148 85.776 54.776 63.859 31
14496.625 0.03126 6.126 73.512 47.455 64.554 26.057
14650.845 0.02605 5.105 61.26 39.967 65.242 21.293
14805.064 0.02084 4.084 49.008 32.31 65.928 16.698
14959.284 0.01563 3.063 36.756 24.485 66.615 12.271
15113.503 0.01042 2.042 24.504 16.492 67.303 8.012
15267.723 0.00521 1.021 12.252 8.33 67.989 3.922
15421.942 0 0 0 0 0 0
Click to expand Motor Curve Data
Speed (RPM) Torque (N·m) Current (A) Supplied Power (W) Output Power (W) Efficiency (%) Power Dissipation (W)
0 0.511 85.947 1031.364 0 0 1031.364
119.976 0.50589 85.105 1021.26 6.356 0.622 1014.904
239.951 0.50078 84.263 1011.156 12.583 1.244 998.573
359.927 0.49567 83.422 1001.064 18.683 1.866 982.381
479.902 0.49056 82.58 990.96 24.653 2.488 966.307
599.878 0.48545 81.738 980.856 30.496 3.109 950.36
719.853 0.48034 80.896 970.752 36.209 3.73 934.543
839.829 0.47523 80.054 960.648 41.795 4.351 918.853
959.804 0.47012 79.212 950.544 47.252 4.971 903.292
1079.78 0.46501 78.371 940.452 52.581 5.591 887.871
1199.755 0.4599 77.529 930.348 57.781 6.211 872.567
1319.731 0.45479 76.687 920.244 62.853 6.83 857.391
1439.706 0.44968 75.845 910.14 67.796 7.449 842.344
1559.682 0.44457 75.003 900.036 72.611 8.068 827.425
1679.657 0.43946 74.161 889.932 77.298 8.686 812.634
1799.633 0.43435 73.32 879.84 81.856 9.304 797.984
1919.608 0.42924 72.478 869.736 86.286 9.921 783.45
2039.584 0.42413 71.636 859.632 90.588 10.538 769.044
2159.559 0.41902 70.794 849.528 94.761 11.155 754.767
2279.535 0.41391 69.952 839.424 98.805 11.771 740.619
2399.51 0.4088 69.11 829.32 102.722 12.386 726.598
2519.486 0.40369 68.269 819.228 106.51 13.001 712.718
2639.461 0.39858 67.427 809.124 110.169 13.616 698.955
2759.437 0.39347 66.585 799.02 113.7 14.23 685.32
2879.412 0.38836 65.743 788.916 117.103 14.844 671.813
2999.388 0.38325 64.901 778.812 120.377 15.456 658.435
3119.364 0.37814 64.059 768.708 123.523 16.069 645.185
3239.339 0.37303 63.218 758.616 126.54 16.68 632.076
3359.315 0.36792 62.376 748.512 129.429 17.292 619.083
3479.29 0.36281 61.534 738.408 132.19 17.902 606.218
3599.266 0.3577 60.692 728.304 134.822 18.512 593.482
3719.241 0.35259 59.85 718.2 137.326 19.121 580.874
3839.217 0.34748 59.008 708.096 139.702 19.729 568.394
3959.192 0.34237 58.167 698.004 141.949 20.336 556.055
4079.168 0.33726 57.325 687.9 144.067 20.943 543.833
4199.143 0.33215 56.483 677.796 146.057 21.549 531.739
4319.119 0.32704 55.641 667.692 147.919 22.154 519.773
4439.094 0.32193 54.799 657.588 149.653 22.758 507.935
4559.07 0.31682 53.957 647.484 151.258 23.361 496.226
4679.045 0.31171 53.116 637.392 152.734 23.962 484.658
4799.021 0.3066 52.274 627.288 154.083 24.563 473.205
4918.996 0.30149 51.432 617.184 155.302 25.163 461.882
5038.972 0.29638 50.59 607.08 156.394 25.762 450.686
5158.947 0.29127 49.748 596.976 157.357 26.359 439.619
5278.923 0.28616 48.906 586.872 158.191 26.955 428.681
5398.898 0.28105 48.065 576.78 158.898 27.549 417.882
5518.874 0.27594 47.223 566.676 159.475 28.142 407.201
5638.849 0.27083 46.381 556.572 159.925 28.734 396.647
5758.825 0.26572 45.539 546.468 160.246 29.324 386.222
5878.8 0.26061 44.697 536.364 160.438 29.912 375.926
5998.776 0.2555 43.856 526.272 160.503 30.498 365.769
6118.752 0.25039 43.014 516.168 160.438 31.083 355.73
6238.727 0.24528 42.172 506.064 160.246 31.665 345.818
6358.703 0.24017 41.33 495.96 159.925 32.246 336.035
6478.678 0.23506 40.488 485.856 159.475 32.824 326.381
6598.654 0.22995 39.646 475.752 158.898 33.399 316.854
6718.629 0.22484 38.805 465.66 158.191 33.971 307.469
6838.605 0.21973 37.963 455.556 157.357 34.542 298.199
6958.58 0.21462 37.121 445.452 156.394 35.109 289.058
7078.556 0.20951 36.279 435.348 155.302 35.673 280.046
7198.531 0.2044 35.437 425.244 154.083 36.234 271.161
7318.507 0.19929 34.595 415.14 152.734 36.791 262.406
7438.482 0.19418 33.754 405.048 151.258 37.343 253.79
7558.458 0.18907 32.912 394.944 149.653 37.892 245.291
7678.433 0.18396 32.07 384.84 147.919 38.436 236.921
7798.409 0.17885 31.228 374.736 146.057 38.976 228.679
7918.384 0.17374 30.386 364.632 144.067 39.51 220.565
8038.36 0.16863 29.544 354.528 141.949 40.039 212.579
8158.335 0.16352 28.703 344.436 139.701 40.559 204.735
8278.311 0.15841 27.861 334.332 137.326 41.075 197.006
8398.286 0.1533 27.019 324.228 134.822 41.582 189.406
8518.262 0.14819 26.177 314.124 132.19 42.082 181.934
8638.237 0.14308 25.335 304.02 129.429 42.573 174.591
8758.213 0.13797 24.493 293.916 126.54 43.053 167.376
8878.188 0.13286 23.652 283.824 123.523 43.521 160.301
8998.164 0.12775 22.81 273.72 120.377 43.978 153.343
9118.14 0.12264 21.968 263.616 117.103 44.422 146.513
9238.115 0.11753 21.126 253.512 113.7 44.85 139.812
9358.091 0.11242 20.284 243.408 110.169 45.261 133.239
9478.066 0.10731 19.442 233.304 106.51 45.653 126.794
9598.042 0.1022 18.601 223.212 102.722 46.02 120.49
9718.017 0.09709 17.759 213.108 98.805 46.364 114.303
9837.993 0.09198 16.917 203.004 94.761 46.679 108.243
9957.968 0.08687 16.075 192.9 90.588 46.961 102.312
10077.944 0.08176 15.233 182.796 86.286 47.203 96.51
10197.919 0.07665 14.391 172.692 81.856 47.4 90.836
10317.895 0.07154 13.55 162.6 77.298 47.539 85.302
10437.87 0.06643 12.708 152.496 72.611 47.615 79.885
10557.846 0.06132 11.866 142.392 67.796 47.612 74.596
10677.821 0.05621 11.024 132.288 62.853 47.512 69.435
10797.797 0.0511 10.182 122.184 57.781 47.29 64.403
10917.772 0.04599 9.34 112.08 52.581 46.914 59.499
11037.748 0.04088 8.499 101.988 47.252 46.331 54.736
11157.723 0.03577 7.657 91.884 41.795 45.487 50.089
11277.699 0.03066 6.815 81.78 36.209 44.276 45.571
11397.674 0.02555 5.973 71.676 30.495 42.546 41.181
11517.65 0.02044 5.131 61.572 24.653 40.039 36.919
11637.625 0.01533 4.289 51.468 18.683 36.3 32.785
11757.601 0.01022 3.448 41.376 12.583 30.411 28.793
11877.576 0.00511 2.606 31.272 6.356 20.325 24.916
11997.552 0 1.764 21.168 0 0 21.168
Click to expand Motor Curve Data
Speed (RPM) Torque (N·m) Current (A) Supplied Power (W) Output Power (W) Efficiency (%) Power Dissipation (W)
0 0.385 63.711 764.532 0 0 764.532
89.885 0.38115 63.093 757.116 3.588 0.474 753.528
179.77 0.3773 62.476 749.712 7.103 0.947 742.609
269.654 0.37345 61.858 742.296 10.546 1.421 731.75
359.539 0.3696 61.241 734.892 13.916 1.894 720.976
449.424 0.36575 60.623 727.476 17.214 2.366 710.262
539.309 0.3619 60.005 720.06 20.439 2.839 699.621
629.193 0.35805 59.388 712.656 23.592 3.31 689.064
719.078 0.3542 58.77 705.24 26.672 3.782 678.568
808.963 0.35035 58.153 697.836 29.68 4.253 668.156
898.848 0.3465 57.535 690.42 32.615 4.724 657.805
988.732 0.34265 56.917 683.004 35.478 5.194 647.526
1078.617 0.3388 56.3 675.6 38.268 5.664 637.332
1168.502 0.33495 55.682 668.184 40.986 6.134 627.198
1258.387 0.3311 55.065 660.78 43.632 6.603 617.148
1348.271 0.32725 54.447 653.364 46.205 7.072 607.159
1438.156 0.3234 53.829 645.948 48.705 7.54 597.243
1528.041 0.31955 53.212 638.544 51.133 8.008 587.411
1617.926 0.3157 52.594 631.128 53.489 8.475 577.639
1707.81 0.31185 51.977 623.724 55.772 8.942 567.952
1797.695 0.308 51.359 616.308 57.982 9.408 558.326
1887.58 0.30415 50.741 608.892 60.12 9.874 548.772
1977.465 0.3003 50.124 601.488 62.186 10.339 539.302
2067.349 0.29645 49.506 594.072 64.179 10.803 529.893
2157.234 0.2926 48.889 586.668 66.1 11.267 520.568
2247.119 0.28875 48.271 579.252 67.948 11.73 511.304
2337.004 0.2849 47.653 571.836 69.724 12.193 502.112
2426.889 0.28105 47.036 564.432 71.427 12.655 493.005
2516.773 0.2772 46.418 557.016 73.058 13.116 483.958
2606.658 0.27335 45.801 549.612 74.616 13.576 474.996
2696.543 0.2695 45.183 542.196 76.102 14.036 466.094
2786.428 0.26565 44.565 534.78 77.515 14.495 457.265
2876.312 0.2618 43.948 527.376 78.856 14.953 448.52
2966.197 0.25795 43.33 519.96 80.124 15.41 439.836
3056.082 0.2541 42.713 512.556 81.32 15.866 431.236
3145.967 0.25025 42.095 505.14 82.444 16.321 422.696
3235.851 0.2464 41.477 497.724 83.494 16.775 414.23
3325.736 0.24255 40.86 490.32 84.473 17.228 405.847
3415.621 0.2387 40.242 482.904 85.379 17.68 397.525
3505.506 0.23485 39.625 475.5 86.212 18.131 389.288
3595.39 0.231 39.007 468.084 86.973 18.581 381.111
3685.275 0.22715 38.389 460.668 87.662 19.029 373.006
3775.16 0.2233 37.772 453.264 88.278 19.476 364.986
3865.045 0.21945 37.154 445.848 88.822 19.922 357.026
3954.929 0.2156 36.537 438.444 89.293 20.366 349.151
4044.814 0.21175 35.919 431.028 89.691 20.809 341.337
4134.699 0.2079 35.301 423.612 90.018 21.25 333.594
4224.584 0.20405 34.684 416.208 90.271 21.689 325.937
4314.468 0.2002 34.066 408.792 90.452 22.127 318.34
4404.353 0.19635 33.449 401.388 90.561 22.562 310.827
4494.238 0.1925 32.831 393.972 90.597 22.996 303.375
4584.123 0.18865 32.213 386.556 90.561 23.428 295.995
4674.008 0.1848 31.596 379.152 90.452 23.856 288.7
4763.892 0.18095 30.978 371.736 90.271 24.284 281.465
4853.777 0.1771 30.361 364.332 90.018 24.708 274.314
4943.662 0.17325 29.743 356.916 89.691 25.129 267.225
5033.547 0.1694 29.125 349.5 89.293 25.549 260.207
5123.431 0.16555 28.508 342.096 88.822 25.964 253.274
5213.316 0.1617 27.89 334.68 88.278 26.377 246.402
5303.201 0.15785 27.273 327.276 87.662 26.785 239.614
5393.086 0.154 26.655 319.86 86.973 27.191 232.887
5482.97 0.15015 26.037 312.444 86.212 27.593 226.232
5572.855 0.1463 25.42 305.04 85.379 27.989 219.661
5662.74 0.14245 24.802 297.624 84.473 28.382 213.151
5752.625 0.1386 24.185 290.22 83.495 28.77 206.725
5842.509 0.13475 23.567 282.804 82.444 29.152 200.36
5932.394 0.1309 22.949 275.388 81.32 29.529 194.068
6022.279 0.12705 22.332 267.984 80.124 29.899 187.86
6112.164 0.1232 21.714 260.568 78.856 30.263 181.712
6202.048 0.11935 21.097 253.164 77.515 30.618 175.649
6291.933 0.1155 20.479 245.748 76.102 30.967 169.646
6381.818 0.11165 19.861 238.332 74.616 31.308 163.716
6471.703 0.1078 19.244 230.928 73.058 31.637 157.87
6561.587 0.10395 18.626 223.512 71.427 31.957 152.085
6651.472 0.1001 18.009 216.108 69.724 32.263 146.384
6741.357 0.09625 17.391 208.692 67.948 32.559 140.744
6831.242 0.0924 16.773 201.276 66.1 32.84 135.176
6921.127 0.08855 16.156 193.872 64.179 33.104 129.693
7011.011 0.0847 15.538 186.456 62.186 33.352 124.27
7100.896 0.08085 14.921 179.052 60.12 33.577 118.932
7190.781 0.077 14.303 171.636 57.982 33.782 113.654
7280.666 0.07315 13.685 164.22 55.772 33.962 108.448
7370.55 0.0693 13.068 156.816 53.489 34.109 103.327
7460.435 0.06545 12.45 149.4 51.133 34.226 98.267
7550.32 0.0616 11.833 141.996 48.705 34.3 93.291
7640.205 0.05775 11.215 134.58 46.205 34.333 88.375
7730.089 0.0539 10.597 127.164 43.632 34.312 83.532
7819.974 0.05005 9.98 119.76 40.986 34.223 78.774
7909.859 0.0462 9.362 112.344 38.268 34.063 74.076
7999.744 0.04235 8.745 104.94 35.478 33.808 69.462
8089.628 0.0385 8.127 97.524 32.615 33.443 64.909
8179.513 0.03465 7.509 90.108 29.68 32.938 60.428
8269.398 0.0308 6.892 82.704 26.672 32.25 56.032
8359.283 0.02695 6.274 75.288 23.592 31.336 51.696
8449.167 0.0231 5.657 67.884 20.439 30.109 47.445
8539.052 0.01925 5.039 60.468 17.213 28.466 43.255
8628.937 0.0154 4.421 53.052 13.916 26.231 39.136
8718.822 0.01155 3.804 45.648 10.546 23.103 35.102
8808.706 0.0077 3.186 38.232 7.103 18.579 31.129
8898.591 0.00385 2.569 30.828 3.588 11.639 27.24
8988.476 0 1.951 23.412 0 0 23.412
Click to expand Motor Curve Data
Speed (RPM) Torque (N·m) Current (A) Supplied Power (W) Output Power (W) Efficiency (%) Power Dissipation (W)
0 0.289 47.509 570.108 0 0 570.108
59.316 0.28611 47.054 564.648 1.777 0.315 562.871
118.633 0.28322 46.599 559.188 3.519 0.629 555.669
177.949 0.28033 46.144 553.728 5.224 0.943 548.504
237.265 0.27744 45.689 548.268 6.893 1.257 541.375
296.581 0.27455 45.234 542.808 8.527 1.571 534.281
355.898 0.27166 44.779 537.348 10.125 1.884 527.223
415.214 0.26877 44.324 531.888 11.686 2.197 520.202
474.53 0.26588 43.869 526.428 13.212 2.51 513.216
533.846 0.26299 43.414 520.968 14.702 2.822 506.266
593.163 0.2601 42.959 515.508 16.156 3.134 499.352
652.479 0.25721 42.504 510.048 17.575 3.446 492.473
711.795 0.25432 42.049 504.588 18.957 3.757 485.631
771.111 0.25143 41.594 499.128 20.303 4.068 478.825
830.428 0.24854 41.139 493.668 21.614 4.378 472.054
889.744 0.24565 40.684 488.208 22.888 4.688 465.32
949.06 0.24276 40.229 482.748 24.127 4.998 458.621
1008.376 0.23987 39.773 477.276 25.33 5.307 451.946
1067.693 0.23698 39.318 471.816 26.496 5.616 445.32
1127.009 0.23409 38.863 466.356 27.627 5.924 438.729
1186.325 0.2312 38.408 460.896 28.722 6.232 432.174
1245.641 0.22831 37.953 455.436 29.781 6.539 425.655
1304.958 0.22542 37.498 449.976 30.805 6.846 419.171
1364.274 0.22253 37.043 444.516 31.792 7.152 412.724
1423.59 0.21964 36.588 439.056 32.743 7.458 406.313
1482.906 0.21675 36.133 433.596 33.659 7.763 399.937
1542.223 0.21386 35.678 428.136 34.539 8.067 393.597
1601.539 0.21097 35.223 422.676 35.382 8.371 387.294
1660.855 0.20808 34.768 417.216 36.19 8.674 381.026
1720.171 0.20519 34.313 411.756 36.962 8.977 374.794
1779.488 0.2023 33.858 406.296 37.698 9.278 368.598
1838.804 0.19941 33.403 400.836 38.398 9.579 362.438
1898.12 0.19652 32.948 395.376 39.062 9.88 356.314
1957.436 0.19363 32.493 389.916 39.691 10.179 350.225
2016.753 0.19074 32.038 384.456 40.283 10.478 344.173
2076.069 0.18785 31.583 378.996 40.84 10.776 338.156
2135.385 0.18496 31.128 373.536 41.36 11.073 332.176
2194.701 0.18207 30.673 368.076 41.845 11.369 326.231
2254.018 0.17918 30.218 362.616 42.294 11.664 320.322
2313.334 0.17629 29.763 357.156 42.707 11.958 314.449
2372.65 0.1734 29.308 351.696 43.084 12.25 308.612
2431.966 0.17051 28.853 346.236 43.425 12.542 302.811
2491.283 0.16762 28.398 340.776 43.73 12.832 297.046
2550.599 0.16473 27.943 335.316 43.999 13.122 291.317
2609.915 0.16184 27.488 329.856 44.232 13.409 285.624
2669.231 0.15895 27.033 324.396 44.43 13.696 279.966
2728.548 0.15606 26.578 318.936 44.591 13.981 274.345
2787.864 0.15317 26.123 313.476 44.717 14.265 268.759
2847.18 0.15028 25.668 308.016 44.807 14.547 263.209
2906.496 0.14739 25.213 302.556 44.861 14.827 257.695
2965.813 0.1445 24.758 297.096 44.879 15.106 252.217
3025.129 0.14161 24.302 291.624 44.861 15.383 246.763
3084.445 0.13872 23.847 286.164 44.807 15.658 241.357
3143.761 0.13583 23.392 280.704 44.717 15.93 235.987
3203.078 0.13294 22.937 275.244 44.591 16.201 230.653
3262.394 0.13005 22.482 269.784 44.43 16.469 225.354
3321.71 0.12716 22.027 264.324 44.232 16.734 220.092
3381.026 0.12427 21.572 258.864 43.999 16.997 214.865
3440.343 0.12138 21.117 253.404 43.73 17.257 209.674
3499.659 0.11849 20.662 247.944 43.425 17.514 204.519
3558.975 0.1156 20.207 242.484 43.084 17.768 199.4
3618.291 0.11271 19.752 237.024 42.707 18.018 194.317
3677.608 0.10982 19.297 231.564 42.294 18.264 189.27
3736.924 0.10693 18.842 226.104 41.845 18.507 184.259
3796.24 0.10404 18.387 220.644 41.36 18.745 179.284
3855.556 0.10115 17.932 215.184 40.84 18.979 174.344
3914.873 0.09826 17.477 209.724 40.283 19.208 169.441
3974.189 0.09537 17.022 204.264 39.691 19.431 164.573
4033.505 0.09248 16.567 198.804 39.062 19.648 159.742
4092.821 0.08959 16.112 193.344 38.398 19.86 154.946
4152.138 0.0867 15.657 187.884 37.698 20.065 150.186
4211.454 0.08381 15.202 182.424 36.962 20.262 145.462
4270.77 0.08092 14.747 176.964 36.19 20.45 140.774
4330.086 0.07803 14.292 171.504 35.382 20.63 136.122
4389.403 0.07514 13.837 166.044 34.539 20.801 131.505
4448.719 0.07225 13.382 160.584 33.659 20.96 126.925
4508.035 0.06936 12.927 155.124 32.743 21.108 122.381
4567.351 0.06647 12.472 149.664 31.792 21.242 117.872
4626.668 0.06358 12.017 144.204 30.805 21.362 113.399
4685.984 0.06069 11.562 138.744 29.781 21.465 108.963
4745.3 0.0578 11.107 133.284 28.722 21.549 104.562
4804.616 0.05491 10.652 127.824 27.627 21.613 100.197
4863.933 0.05202 10.197 122.364 26.496 21.653 95.868
4923.249 0.04913 9.742 116.904 25.33 21.667 91.574
4982.565 0.04624 9.286 111.432 24.127 21.652 87.305
5041.881 0.04335 8.831 105.972 22.888 21.598 83.084
5101.198 0.04046 8.376 100.512 21.614 21.504 78.898
5160.514 0.03757 7.921 95.052 20.303 21.36 74.749
5219.83 0.03468 7.466 89.592 18.957 21.159 70.635
5279.146 0.03179 7.011 84.132 17.574 20.889 66.558
5338.463 0.0289 6.556 78.672 16.156 20.536 62.516
5397.779 0.02601 6.101 73.212 14.702 20.081 58.51
5457.095 0.02312 5.646 67.752 13.212 19.501 54.54
5516.411 0.02023 5.191 62.292 11.686 18.76 50.606
5575.728 0.01734 4.736 56.832 10.125 17.816 46.707
5635.044 0.01445 4.281 51.372 8.527 16.599 42.845
5694.36 0.01156 3.826 45.912 6.893 15.014 39.019
5753.676 0.00867 3.371 40.452 5.224 12.914 35.228
5812.993 0.00578 2.916 34.992 3.518 10.054 31.474
5872.309 0.00289 2.461 29.532 1.777 6.017 27.755
5931.625 0 2.006 24.072 0 0 24.072
Click to expand Peak Power Test Data
Time (s) Current (A) Power Out (W)
0 83.23 374.025
0.366 81.84 370.786
0.769 81.76 365.003
1.173 80.54 359.48
1.552 78.87 353.183
1.935 76.79 350.17
2.312 75.89 346.329
2.662 75.46 343.624
3.008 74.15 338.585
3.36 73.62 337.315
3.736 73.22 332.655
4.085 72.27 330.423
4.434 71.33 329.69
4.782 71.21 327.912
5.132 70.75 327.371
5.49 70.33 325.591
5.847 69.12 323.355
6.206 69.22 320.728
6.557 68.62 318.512
6.958 67.6 314.731
7.307 66.79 309.884
7.656 65.43 307.163
8.007 64.99 304.915
8.383 64.29 303.244
8.731 63.79 303.566
9.082 63.56 296.495
9.429 62.63 292.702
9.779 61.62 290.076
10.128 61.24 282.945
10.505 59.66 276.338
10.855 57.72 264.085
11.24 55.41 247.262
11.622 52.82 234.105
11.981 47.25 207.43
12.331 43.47 205.56
12.707 41.04 190.745
13.056 39.82 210.064
13.406 40.76 200.818
13.755 42.51 200.77
14.142 43.02 209.424
14.496 42.87 214.784
14.856 42.7 217.899
15.206 44.86 216.171
15.583 43.56 216.604
15.932 46.5 219.33
16.281 47.02 225.611
16.629 46.61 227.845
16.98 46.9 192.559
17.329 47.16 228.422
17.679 46.83 225.524
18.054 49.54 238.109
18.404 49.78 233.787
18.806 49.54 236.655
19.155 49.92 221.411
19.505 45.92 228.085
19.854 46.91 245.432
20.202 49.99 243.202
20.551 50 241.485
20.928 50.42 234.938
21.277 48.97 233.578
21.626 50.11 228.921
21.976 47.85 227.763
22.326 48.19 231.73
22.673 49 218.042
23.035 47.45 228.464
23.399 47.98 237.296
23.748 48.94 237.078
24.097 49.8 237.801
24.447 49.98 233.908
24.823 49.85 238.991
25.172 49.45 232.305
25.522 48.81 229.754
25.942 48.15 222.32
26.328 47.3 221.165
26.693 47.69 232.057
27.052 46.84 227.361
27.401 45.62 218.17
27.75 43.63 220.428
28.127 45.08 216.042
28.477 45.61 205.025
28.879 44.02 205.424
29.228 44.97 210.784
29.577 44.82 208.808
29.928 43.48 196.792
30.276 41.6 187.373
30.625 39.42 194.662
31 39.09 194.339
31.35 41.89 193.246
31.698 42.22 202.78
32.048 41.44 193.451
32.397 42.03 199.222
32.748 40.94 197.248
33.099 43.36 204.988
33.456 42.39 195.503
33.813 42.24 198.307
34.172 41.45 192.265
34.521 40.51 185.319
34.871 39.91 191.971
35.247 40.28 179.061
35.612 39.91 193.428
35.972 40.08 199.128
36.347 42.16 200.182
36.697 40.65 188.061
37.046 40.08 190.642
37.395 39.69 182.161
37.744 40.21 176.779
38.122 42.35 194
38.468 41.65 189.127
38.819 40.97 209.623
39.168 41.85 181.83
39.518 41.54 196.693
39.867 41.68 190.597
40.245 38.76 193.749
40.591 42.14 204.125
40.941 38.29 190.7
41.291 39.19 191.285
41.641 38.89 186.837
41.989 39.62 180.269
42.35 40.57 184.796
42.715 41.32 181.755
43.066 42.43 199.43
43.467 41.42 205.257
43.817 41.32 209.121
44.166 42.3 208.251
44.513 44.31 202.518
44.863 42.76 196.932
45.212 40.83 182.796
45.59 39.84 192.298
45.938 39.8 182.56
46.289 40.06 200.16
46.636 39.84 205.426
46.986 40.12 183.576
47.362 41.13 179.844
47.711 38.08 177.28
48.06 41.1 182.674
48.463 39.74 184.189
48.811 39.85 181.332
49.16 39.36 185.057
49.511 41.68 205.085
49.859 40.51 191.195
50.238 40.1 187.218
50.586 41.6 204.403
50.936 42.58 192.587
51.283 41.84 192.656
51.634 40.42 186.309
51.983 39.95 198.466
52.359 41.25 199.597
52.761 41.63 196.901
53.126 40.32 189.461
53.487 39.77 197.536
53.836 41.13 192.356
54.187 40.94 206.799
54.562 41.31 198.66
54.965 41.8 200.701
55.33 42.83 187.947
55.69 41.91 193.931
56.092 41.47 193.658
56.442 40.78 188.194
56.791 39.51 193.224
57.14 39.98 180.63
57.516 40.01 196.586
57.865 41.75 208.959
58.215 43.49 200.182
58.563 42.18 188.725
58.913 41.7 189.55
59.262 40.77 189.171
59.612 40.7 193.11
59.988 42.24 200.583
60.336 41.96 203.568
60.686 43.21 210.068
61.035 43.24 209.895
61.384 42.77 208.484
61.761 43.75 208.735
62.136 43.6 206.337
62.485 43.53 206.75
62.861 43.15 201.819
63.209 43.41 208.459
63.56 44.74 208.239
63.908 43.64 205.23
64.256 43.69 205.973
64.633 42.79 195.999
64.982 42.11 207.479
65.332 43.75 195.319
65.681 42.82 201.545
66.029 42.03 204.436
66.378 43.59 201.344
66.738 42.95 198.094
67.093 43.01 204.101
67.455 43.5 207.617
67.803 43.25 208.386
68.153 43.16 210.562
68.529 43.88 210.685
68.878 44.61 212.663
69.228 45.16 208.562
69.577 43.9 197.234
69.926 43.31 209.005
70.275 41.74 204.101
70.651 43.72 204.992
70.999 44.01 213.088
71.35 43.56 210.933
71.698 44.81 213.239
72.075 45 203.645
72.424 44.63 206.337
72.773 44.6 203.645
73.122 42.88 202.875
73.472 42.88 205.617
73.819 42.44 207.91
74.196 43.13 203.813
74.545 41.84 200.812
74.894 43.59 201.119
75.243 43.22 207.593
75.592 43.79 205.254
75.942 42.56 206.556
76.317 44.16 210.191
76.668 44.21 205.762
77.017 43.05 204.775
77.366 43.3 201.545
77.769 43.61 204.823
78.118 43.52 206.969
78.466 42.98 203.429
78.816 43.59 205.835
79.192 43.37 202.422
79.541 42.71 191.858
79.892 42.94 208.925
80.239 42.24 202.675
80.589 44.05 203.693
80.966 44.35 205.876
81.314 42.62 207.568
81.664 44.11 205.876
82.013 43.18 204.029
82.364 42.69 202.318
82.713 43.21 200.276
83.115 42.85 196.716
83.464 43.45 208.081
83.812 43.95 203.837
84.189 43.37 200.93
84.538 42.92 196.924
84.888 42.87 198.963
85.237 43.19 200.088
85.586 42.7 200.559
85.936 42.62 201.072
86.312 42.09 198.8
86.661 42.65 201.486
87.012 42.69 186.907
87.413 41.85 195.666
87.763 42.58 198.025
88.112 43.31 197.133
88.461 43.31 197.792
88.809 42.91 199.621
89.169 43.38 193.772
89.554 42.8 194.431
89.91 42.8 195.688
90.262 42.53 194.959
90.637 43.41 194.114
90.987 43.16 192.565
91.372 41.16 190.239
91.755 42.01 196.994
92.114 42.62 132.311
92.463 65.88 116.224
92.84 65.09 107.4
93.19 62.84 104.303
93.591 62.4 72.527
93.941 92.27 30.824
94.29 2.53 35.274
94.639 0 10.345
94.987 0 3.647
95.338 0 1.118
95.686 0 0.165
96.064 0 0.034
96.41 0 0
96.774 0 0
97.146 0 0
97.501 0 0
97.861 0 0
98.21 0 0
98.569 0 0
98.951 0 0
99.323 0 0
99.703 0 0
100.082 0 0
100.465 0 0
100.816 0 0
101.164 0 0
101.514 0 0
101.89 0 0
102.28 0 0
102.654 0 0
103.007 0 0
103.381 0 0
103.756 0 0
104.11 0 0
104.508 0 0
104.875 0 0
105.238 0 0
105.626 0 0
105.986 0 0
106.34 0 0
106.701 0 0
107.076 0 0
107.426 0 0
107.774 0 0
108.123 0 0
108.482 0 0
108.849 0 0
109.197 0 0
109.545 0 0
109.894 0 0
110.284 0 0
110.676 0 0
111.034 0 0
111.39 0 0
111.748 0 0
112.112 0 0
112.489 0 0
112.849 0 0
113.199 0 0
113.549 0 0
